Application:
1. Aquatic product classification: fresh fish, shrimp, abalone and other aquatic products;
2. Poultry product classification: chicken wings, chicken legs, chicken feet, whole chickens, ducks and other poultry products;
3. Fruit and vegetable classification: apples, oranges, potatoes and other fruit and vegetable products.
Features:
1. Use imported special dynamic weighing unit to realize high-speed and stable measurement;
2. large-size color touch screen interface, simple operation and intuitive display;
3. Fully automatic sorting method to avoid human error;
4. Automatic zero point analysis and tracking system to ensure stable detection;
5. Built-in temperature noise compensation system to ensure reliable data;
6. Powerful data statistics function, record daily inspection data, can store 100 sets of product data, convenient for customers use, and sudden power failure data will not be lost;
7. The conveying system adopts frequency conversion speed regulation mode, which is convenient for front and rear speed coordination;
8. Dynamic weight compensation technology, the detection data is more real and effective;
9. Self-fault diagnosis and prompt function, convenient for maintenance;
10. Use reinforced stainless steel 304 frame, in line with high standards and HACCP specifications;
11. Simple mechanical structure, which can be quickly disassembled for cleaning and maintenance;
Technical parameters
Model MK06S MK06M MK06L
Sorting grades 5-12 5-12 5-12
Sorting speed 320 pcs/min 240 pcs/min 160 pcs/min
Sorting accuracy 0.1g 1g 1g
Sorting error ﹤±1g ﹤±5g ﹤±10g
Weighing range 5g~200g 50-1000g 50-5000g
Weight sensor HBM HBM HBM
Materials SUS304 SUS304 SUS304
Voltage AC220V/50HZ
Power 500W 500W 2500W
Protection level IP65 IP65 IP65
Working environment temperature: 0-40℃
Humidity: 30%-95%
